SGCC SPCC Pre Painted Galvalume Sheet Roofing GI Steel Plate 0.3mm 0.4mm 0.46mm 0.5mm

Ask Lasest Price
Price :	Negotiable
Delivery Time :	10-30 Days
Payment Terms :	LC, T/T, D/P, PayPal, Western Union

Add to Cart

Product Details
Company Profile

SGCC SPCC Pre Painted Galvalume Sheet Roofing GI Steel Plate 0.3mm 0.4mm 0.46mm 0.5mm

Our company mainly produces: GI/PRE-PAINTED COLOR /PATTERN COIL/PLATE ,GI/PPGI ROOFING SHEET , Galvalume Steel Coil,PLATE,SECTION STEEL,H BEAMC BEAM,I BEAM,ANGLE STEEL,DEFORMED STEEL BAR,STEEL WIREROD,SEAMLESSS TEEL PIPE and so on.

If you need the above products, please contact us and we will give you a satisfactory price.

Galvanized Steel
Technical Standard	EN10147/EN10142/DIN 17162/JIS G3302/ASTM A653
Steel Grade	Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type	Coil/Sheet/Plate/Strip
Thicness	0.12～6.0mm or customer's requirement
Width	600～1500mm according to customer's requirement
Type of Coating	Hot Dipped Galvanized Steel(HDGI)
Zinc Coating	30-275g/m2
Surface Treatment	Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure	Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality	Approved by SGS,ISO
ID	508mm/610mm
Coil Weight	3-20 metric ton per coil
Package	Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
Export market	Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc

Hot-dip galvanizing is the reaction of molten metal with an iron substrate to produce an alloy layer, thereby combining the substrate and the plating layer. Hot-dip galvanizing is to pickle iron and steel parts first. In order to remove iron oxide on the surface of iron and steel parts, after pickling, it is cleaned in an ammonium chloride or zinc chloride aqueous solution or a mixed solution of ammonium chloride and zinc chloride.And then sent to the hot-dip plating bath. Hot-dip galvanizing has the advantages of uniform coating, strong adhesion and long service life.

What are advantages of galvanized steel?
Because it is produced through applying Zn coat on both faces by hot dip process. It enjoys both the physical protective feature and the electrochemical protective property of Zn.
>>Machin ability: It can satisfy the processing requirements of rolling, coiling and others processes alike.
>>Thermal resistance: Common HDG steel plate normally works under 230℃, and has its color changed at 250℃, however, Galvanized steel plate can sustain the environment at 315℃ for long time.
>>High reflectivity: Reflection ability of heat and light is twice as much as those of hot-dip zinc steel sheet, and its
reflectivity is more than 0.70, which is an ideal construction materials of saving energy.

About Us

Shandong Dingcheng Liye Material Company is a domestic modern iron and steel enterprise who is founded in 2015. Specialized in Carbon steel, alloy steel galvanized steel pipe and tube, plate and coil,profiles.We are located in Shandong Province and we are close to Qingdao Seaport, that is much convenient in carriage Since our establishment we have always adhered to the business policy of "sincerity, mutual benefit, high efficiency,high quality”tent, to provide stable resources for domestic and foreign large-scale engineering projects for a long time. Complete specifications, adequate supply, standing inventory of more than 15000 tons. Company adhering to:"Customer first. A win-win situation"business philosophy. adhere to the "Customer first" principle to provide quality services for our customers. Look forward to working with you and serving you.
